Chapter 14. If Wishes Were Horses: The Lojban Connective System

Lojban is a logical language: the name of the language itself means “logical language”. The fundamentals of ordinary logic (there are variant logics, which aren't addressed in this book) include the notions of a “sentence” (sometimes called a “statement” or “proposition”), which asserts a truth or falsehood, and a small set of “truth functions”, which combine two sentences to create a new sentence. The truth functions have the special characteristic that the truth value (that is, the truth or falsehood) of the results depends only on the truth value of the component sentences. For example,

is true if “John is a man” is true, or if “James is a woman” is true. If we know whether John is a man, and we know whether James is a woman, we know whether “John is a man or James is a woman” is true, provided we know the meaning of “or”. Here “John is a man” and “James is a woman” are the component sentences.

We will use the phrase “negating a sentence” to mean changing its truth value. An English sentence may always be negated by prefixing “It is false that ...”, or more idiomatically by inserting “not” at the right point, generally before the verb. “James is not a woman” is the negation of “James is a woman”, and vice versa. Recent slang can also negate a sentence by following it with the exclamation “Not!”

Words like “or” are called “logical connectives”, and Lojban has many of them, as befits a logical language. This chapter is mostly concerned with explaining the forms and uses of the Lojban logical connectives. There are a number of other logical connectives in English such as “and”, “and/or”, “if”, “only if”, “whether or not”, and others; however, not every use of these English words corresponds to a logical connective. This point will be made clear in particular cases as needed. The other English meanings are supported by different Lojban connective constructs.

The Lojban connectives form a system (as the title of this chapter suggests), regular and predictable, whereas natural-language connectives are rather less systematic and therefore less predictable.

There exist 16 possible different truth functions. A truth table is a graphical device for specifying a truth function, making it clear what the value of the truth function is for every possible value of the component sentences. Here is a truth table for “or”:

This table means that if the first sentence stated is true, and the second sentence stated is true, then the result of the truth function is also true. The same is true for every other possible combination of truth values except the one where both the first and the second sentences are false, in which case the truth value of the result is also false.

Suppose that “John is a man” is true (and “John is not a man” is false), and that “James is a woman” is false (and “James is not a woman” is true). Then the truth table tells us that

“John is a man, or James is not a woman” (true true ) is true

“John is a man, or James is a woman” (true , false) is true

“John is not a man, or James is not a woman” (false, true ) is true

“John is not a man, or James is a woman” (false, false) is false

Note that the kind of “or” used in this example can also be expressed (in formal English) with “and/or”. There is a different truth table for the kind of “or” that means “either ... or ... but not both”.

To save space, we will write truth tables in a shorter format henceforth. Let the letters T and F stand for True and False. The rows will always be given in the order shown above: TT, TF, FT, FF for the two sentences. Then it is only necessary to give the four letters from the result column, which can be written TTTF, as can be seen by reading down the third column of the table above. So TTTF is the abbreviated truth table for the “or” truth function. Here are the 16 possible truth functions, with an English version of what it means to assert that each function is, in fact, true (“first” refers to the first sentence, and “second” to the second sentence):

Skeptics may work out the detailed truth tables for themselves.

Lojban regards four of these 16 truth functions as fundamental, and assigns them the four vowels A, E, O, and U. These letters do not represent actual cmavo or selma'o, but rather a component vowel from which actual logical-connective cmavo are built up, as explained in the next section. Here are the four vowels, their truth tables, and rough English equivalents:

More precisely:

A is true if either or both sentences are true

E is true if both sentences are true, but not otherwise

O is true if the sentences are both true or both false

U is true if the first sentence is true, regardless of the truth value of the second sentence

With the four vowels, the ability to negate either sentence, and the ability to exchange the sentences, as if their order had been reversed, we can create all of the 16 possible truth functions except TTTT and FFFF, which are fairly useless anyway. The following table illustrates how to create each of the 14 remaining truth functions:

Note that exchanging the sentences is only necessary with U. The three other basic truth functions are commutative; that is, they mean the same thing regardless of the order of the component sentences. There are other ways of getting some of these truth tables; these just happen to be the methods usually employed.

In order to remain unambiguous, Lojban cannot have only a single logical connective for each truth function. There are many places in the grammar of the language where logical connection is permitted, and each must have its appropriate set of connectives. If the connective suitable for sumti were used to connect selbri, ambiguity would result.

Consider the English sentence:

where the last word could be followed by “the door”, a noun phrase, or by “saw the horses”, a sentence with subject omitted, or by “John went to the door”, a full sentence, or by one of a variety of other English grammatical constructions. Lojban cannot tolerate such grammatical looseness.

Instead, there are a total of five different selma'o used for logical connection: A, GA, GIhA, GUhA, and JA. Each of these includes four cmavo, one based on each of the four vowels, which is always the last vowel in the cmavo. In selma'o A, the vowel is the entire cmavo.

Thus, in selma'o A, the cmavo for the function A is a. (Do not confuse A, which is a selma'o, with A, which is a truth function, or a, which is a cmavo.) Likewise, the cmavo for E in selma'o GIhA is gi'e, and the cmavo for U in selma'o GA is gu. This systematic regularity makes the cmavo easier to learn.

Obviously, four cmavo are not enough to express the 14 truth functions explained in Section 14.1. Therefore, compound cmavo must be used. These compound cmavo follow a systematic pattern: each has one cmavo from the five logical connection selma'o at its heart, and may also contain one or more of the auxiliary cmavo se, na, or nai. Which auxiliaries are used with which logical connection cmavo, and with what grammar and meaning, will be explained in the following sections. The uses of each of these auxiliary cmavo relates to its other uses in other parts of Lojban grammar.

For convenience, each of the types of compound cmavo used for logical connection is designated by a Lojban name. The name is derived by changing the final “-A” of the selma'o name to “-ek”; the reasons for using “-ek” are buried deep in the history of the Loglan Project. Thus, compound cmavo based on selma'o A are known as eks, and those based on selma'o JA are known as jeks. (When writing in English, it is conventional to use “eks” as the plural of “ek”.) When the term “logical connective” is used in this chapter, it refers to one or more of these kinds of compound cmavo.

Why does the title of this section refer to “six types” when there are only five selma'o? A jek may be preceded by i, the usual Lojban cmavo for connecting two sentences. The compound produced by i followed by a jek is known as an ijek. It is useful to think of ijeks as a sixth kind of logical connective, parallel to eks, jeks, geks, giheks, and guheks.

There also exist giks, joiks, ijoiks, and joigiks, which are not logical connectives, but are other kinds of compound cmavo which will be introduced later.

Now we are ready to express Example 14.1 in Lojban! The kind of logical connective which is placed between two Lojban bridi to connect them logically is an ijek:

Here we have two separate Lojban bridi, la djan. nanmu and la djeimyz. ninmu. These bridi are connected by .ija, the ijek for the truth function A. The i portion of the ijek tells us that we are dealing with separate sentences here. Similarly, we can now say:

To obtain the other truth tables listed in Section 14.2, we need to know how to negate the two bridi which represent the component sentences. We could negate them directly by inserting na before the selbri, but Lojban also allows us to place the negation within the connective itself.

To negate the first or left-hand bridi, prefix na to the JA cmavo but after the i. To negate the second or right-hand bridi, suffix -nai to the JA cmavo. In either case, the negating word is placed on the side of the connective that is closest to the bridi being negated.

So to express the truth table FTTF, which requires O with either of the two bridi negated (not both), we can say either:

The meaning of both Example 14.7 and Example 14.8 is the same as that of:

Here is another example:

How's that again? Are those two English sentences in Example 14.10 really equivalent? In English, no. The Lojban TTFT truth function can be glossed “A if B”, but the “if” does not quite have its English sense. Example 14.10 is true so long as John is a man, even if James is not a woman; likewise, it is true just because James is not a woman, regardless of John's gender. This kind of “if-then” is technically known as a “material conditional”.

Since James is not a woman (by our assertions in Section 14.1), the English sentence “John is a man if James is a woman” seems to be neither true nor false, since it assumes something which is not true. It turns out to be most convenient to treat this “if” as TTFT, which on investigation means that Example 14.10 is true. Example 14.11, however, is equally true:

This can be thought of as a principle of consistency, and may be paraphrased as follows: “If a false statement is true, any statement follows from it.” All uses of English “if” must be considered very carefully when translating into Lojban to see if they really fit this Lojban mold.

Example 14.12, which uses the TFTT truth function, is subject to the same rules: the stated gloss of TFTT as “only if” works naturally only when the right-hand bridi is false; if it is true, the left-hand bridi may be either true or false. The last gloss of Example 14.12 illustrates the use of “if ... then” as a more natural substitute for “only if”.

The following example illustrates the use of se to, in effect, exchange the two sentences. The normal use of se is to (in effect) transpose places of a bridi, as explained in Section 5.11.

If both na and se are present, which is legal but never necessary, na would come before se.

The full syntax of ijeks, therefore, is:

where the cmavo in brackets are optional.

Many concepts in Lojban are expressible in two different ways, generally referred to as “afterthought” and “forethought”. Section 14.4 discussed what is called “afterthought bridi logical connection”. The word “afterthought” is used because the connective cmavo and the second bridi were added, as it were, afterwards and without changing the form of the first bridi. This form might be used by someone who makes a statement and then wishes to add or qualify that statement after it has been completed. Thus,

is a complete bridi, and adding an afterthought connection to make

provides additional information without requiring any change in the form of what has come before; changes which may not be possible or practical, especially in speaking. (The meaning, however, may be changed by the use of a negating connective.) Afterthought connectives make it possible to construct all the important truth-functional relationships in a variety of ways.

In forethought style the speaker decides in advance, before expressing the first bridi, that a logical connection will be expressed. Forethought and afterthought connectives are expressed with separate selma'o. The forethought logical connectives corresponding to afterthought ijeks are geks:

ga is the cmavo which represents the A truth function in selma'o GA. The word gi does not belong to GA at all, but constitutes its own selma'o: it serves only to separate the two bridi without having any content of its own. The English translation of ga…gi is “either ... or”, but in the English form the truth function is specified both by the word “either” and by the word “or”: not so in Lojban.

Even though two bridi are being connected, geks and giks do not have any i in them. The forethought construct binds up the two bridi into a single sentence as far as the grammar is concerned.

Some more examples of forethought bridi connection are:

It is worth emphasizing that Example 14.18 does not assert that James is (or is not) a woman. The gu which indicates that la djeimyz. ninmu may be true or false is unfortunately rather remote from the bridi thus affected.

Perhaps the most important of the truth functions commonly expressed in forethought is TFTT, which can be paraphrased as “if ... then ...”:

Note the placement of the nai in Example 14.19. When added to afterthought selma'o such as JA, a following nai negates the second bridi, to which it is adjacent. Since GA cmavo precede the first bridi, a following nai negates the first bridi instead.

Why does English insist on forethought in the translation of Example 14.19? Possibly because it would be confusing to seemingly assert a sentence and then make it conditional (which, as the Lojban form shows, involves a negation). Truth functions which involve negating the first sentence may be confusing, even to the Lojbanic understanding, when expressed using afterthought.

It must be reiterated here that not every use of English “if ... then” is properly translated by .inaja or ganai…gi; anything with implications of time needs a somewhat different Lojban translation, which will be discussed in Section 14.18. Causal sentences like “If you feed the pig, then it will grow” are not logical connectives of any type, but rather need a translation using rinka as the selbri joining two event abstractions, thus:

Causality is discussed in far more detail in Section 9.7.

Example 14.21 and Example 14.22 illustrates a truth function, FTTF, which needs to negate either the first or the second bridi. We already understand how to negate the first bridi:

How can the second bridi be negated? By adding -nai to the gi.

A compound cmavo based on gi is called a gik; the only giks are gi itself and ginai.

Further examples:

The syntax of geks is:

and of giks (which are not themselves connectives, but part of the machinery of forethought connection) is:

Geks and ijeks are sufficient to state every possible logical connection between two bridi. However, it is often the case that two bridi to be logically connected have one or more portions in common:

Here only a single sumti differs between the two bridi. Lojban does not require that both bridi be expressed in full. Instead, a single bridi can be given which contains both of the different sumti and uses a logical connective from a different selma'o to combine the two sumti:

Example 14.26 means exactly the same thing as Example 14.25: one may be rigorously transformed into the other without any change of logical meaning. This rule is true in general for every different kind of logical connection in Lojban; all of them, with one exception (see Section 14.12), can always be transformed into a logical connection between sentences that expresses the same truth function.

The afterthought logical connectives between sumti are eks, which contain a connective cmavo of selma'o A. If ijeks were used in Example 14.26, the meaning would be changed:

leaving the reader uncertain why John is mentioned at all.

Any ek may be used between sumti, even if there is no direct English equivalent:

The second line of Example 14.27 is highly stilted English, but the first line (of which it is a literal translation) is excellent Lojban.

What about forethought sumti connection? As is the case for bridi connection, geks are appropriate. They are not the only selma'o of forethought logical-connectives, but are the most commonly used ones.

Of course, eks include all the same patterns of compound cmavo that ijeks do. When na or se is part of an ek, a special writing convention is invoked, as in the following example:

Note the period in na.a. The cmavo of A begin with vowels, and therefore must always be preceded by a pause. It is conventional to write all connective compounds as single words (with no spaces), but this pause must still be marked in writing as in speech; otherwise, the na and a would tend to run together.

So far we have seen logical connectives used to connect exactly two sentences. How about connecting three or more? Is this possible in Lojban? The answer is yes, subject to some warnings and some restrictions.

Of the four primitive truth functions A, E, O, and U, all but O have the same truth values no matter how their component sentences are associated in pairs. Therefore,

means that all three component sentences are true. Likewise,

means that one or more of the component sentences is true.

O, however, is different. Working out the truth table for

shows that Example 14.33 does not mean that either I am all three of these things or none of them; instead, an accurate translation would be:

Because of the counterintuitiveness of this outcome, it is safest to avoid O with more than two sentences. Likewise, the connectives which involve negation also have unexpected truth values when used with more than two sentences.

In fact, no combination of logical connectives can produce the “all or none” interpretation intended (but not achieved) by Example 14.33 without repeating one of the bridi. See Example 14.48.

There is an additional difficulty with the use of more than two sentences. What is the meaning of:

Does this mean:

Or is the correct translation:

Example 14.36 is the correct translation of Example 14.34. The reason is that Lojban logical connectives pair off from the left, like many constructs in the language. This rule, called the left-grouping rule, is easy to forget, especially when intuition pulls the other way. Forethought connectives are not subject to this problem:

is equivalent in meaning to Example 14.34, whereas

is not equivalent to Example 14.34, but is instead a valid translation into Lojban, using forethought, of Example 14.35.

There are several ways in Lojban to render Example 14.35 using afterthought only. The simplest method is to make use of the cmavo bo (of selma'o BO). This cmavo has several functions in Lojban, but is always associated with high precedence and short scope. In particular, if bo is placed after an ijek, the result is a grammatically distinct kind of ijek which overrides the regular left-grouping rule. Connections marked with bo are interpreted before connections not so marked. Example 14.39 is equivalent in meaning to Example 14.38:

The English translation feebly indicates with a comma what the Lojban marks far more clearly: the “I like Martha” and “I like Mary” sentences are joined by .ija first, before the result is joined to “I like John” by .ije.

Eks can have bo attached in exactly the same way, so that Example 14.40 is equivalent in meaning to Example 14.39:

Forethought connectives, however, never can be suffixed with bo, for every use of forethought connectives clearly indicates the intended pattern of grouping.

What happens if bo is used on both connectives, giving them the same high precedence, as in Example 14.41?

Does this wind up meaning the same as Example 14.34 and Example 14.36? Not at all. A second rule relating to bo is that where several bo-marked connectives are used in succession, the normal Lojban left-grouping rule is replaced by a right-grouping rule. As a result, Example 14.41 in fact means the same as Example 14.39 and Example 14.40. This rule may be occasionally exploited for special effects, but is tricky to keep straight; in writing intended to be easy to understand, multiple consecutive connectives marked with bo should be avoided.

The use of bo, therefore, gets tricky in complex connections of more than three sentences. Looking back at the English translations of Example 14.37 and Example 14.38, parentheses were used to clarify the grouping. These parentheses have their Lojban equivalents, two sets of them actually. tu'e and tu'u are used with ijeks, and ke and ke'e with eks and other connectives to be discussed later. (ke and ke'e are also used in other roles in the language, but always as grouping markers). Consider the English sentence:

where the semantics tells us that the instances of “and” are meant to have higher precedence than that of “if”. If we wish to express Example 14.42 in afterthought, we can say:

marking two of the ijeks with bo for high precedence. (The first bo is not strictly necessary, because of the left-grouping rule, and is shown here in brackets.)

But it may be clearer to use explicit parenthesis words and say:

where the tu'e…tu'u pairs set off the structure. The cmavo tu'u is an elidable terminator, and its second occurrence in Example 14.44 is bracketed, because all terminators may be elided at the end of a text.

In addition, parentheses are a general solution: multiple parentheses may be nested inside one another, and additional afterthought material may be added without upsetting the existing structure. Neither of these two advantages apply to bo grouping. In general, afterthought constructions trade generality for simplicity.

Because of the left-grouping rule, the first set of tu'e…tu'u parentheses may actually be left off altogether, producing:

What about parenthesized sumti connection? Consider

Two pairs of parentheses, analogous to Example 14.44, would seem to be the right approach. However, it is a rule of Lojban grammar that a sumti may not begin with ke, so the first set of parentheses must be omitted, producing Example 14.47, which is instead parallel to Example 14.45:

If sumti were allowed to begin with ke, unavoidable ambiguities would result, so ke grouping of sumti is allowed only just after a logical connective. This rule does not apply to tu'e grouping of bridi, as Example 14.44 shows.

Now we have enough facilities to handle the problem of Example 14.33: “I am German, rich, and a man – or else none of these.” The following paraphrase has the correct meaning:

The truth table, when worked out, produces T if and only if all three component sentences are true or all three are false.

So far we have seen how to handle two sentences that need have no similarity at all (bridi connection) and sentences that are identical except for a difference in one sumti (sumti connection). It would seem natural to ask how to logically connect sentences that are identical except for having different selbri.

Surprise! Lojban provides no logical connective that is designed to handle selbri and nothing else. Instead, selbri connection is provided as part of a more general-purpose mechanism called “compound bridi”. Compound bridi result from logically connecting sentences that differ in their selbri and possibly some of their sumti.

The simplest cases result when the x1 sumti is the only common point:

is equivalent in meaning to the compound bridi:

As Example 14.50 indicates, giheks are used in afterthought to create compound bridi; gi'e is the gihek corresponding to “and”. The actual phrases klama le zarci and nelci la djan. that the gihek connects are known as “bridi-tails”, because they represent (in this use) the “tail end” of a bridi, including the selbri and any following sumti, but excluding any sumti that precede the selbri:

In Example 14.51, the first bridi-tail is ricfu, a simple selbri, and the second bridi-tail is klama le zarci, a selbri with one following sumti.

Suppose that more than a single sumti is identical between the two sentences:

In Example 14.52, the first and last sumti of each bridi are identical; the selbri and the second sumti are different. By moving the final sumti to the beginning, a form analogous to Example 14.50 can be achieved:

where the fi does not have an exact English translation because it merely places do in the third place of both lebna and dunda. However, a form that preserves natural sumti order also exists in Lojban. Giheks connect two bridi-tails, but also allow sumti to be added following the bridi-tail. These sumti are known as tail-terms, and apply to both bridi. The straightforward gihek version of Example 14.52 therefore is:

The vau (of selma'o VAU) serves to separate the bridi-tail from the tail-terms. Every bridi-tail is terminated by an elidable vau, but only in connection with compound bridi is it ever necessary to express this vau. Thus:

has a single elided vau, and Example 14.50 is equivalent to:

where the double vau at the end of Example 14.56 terminates both the right-hand bridi-tail and the unexpressed tail-terms.

A final use of giheks is to combine bridi-tails used as complete sentences, the Lojban observative:

Since x1 is omitted in both of the bridi underlying Example 14.57, this compound bridi does not necessarily imply that the goer and the walker are the same. Only the presence of an explicit x1 (other than zo'e, which is equivalent to omission) can force the goer and the walker to be identical.

A strong argument for this convention is provided by analysis of the following example:

If the rule were that the x1 places of the two underlying bridi were considered identical, then (since there is nothing special about x1), the unspecified x4 (route) and x5 (means) places would also have to be the same, leading to the absurd result that the route from Phoenix to New York is the same as the route from Rome to New York. Inserting da, meaning roughly “something”, into the x1 place cures the problem:

The syntax of giheks is:

which is exactly parallel to the syntax of eks.

Giheks can be combined with bo in the same way as eks:

is equivalent in meaning to Example 14.39 and Example 14.40. Likewise, ke…ke'e grouping can be used after giheks:

is the gihek version of Example 14.47. The same rule about using ke…ke'e bracketing only just after a connective applies to bridi-tails as to sumti, so the first two bridi-tails in Example 14.61 cannot be explicitly grouped; implicit left-grouping suffices to associate them.

Each of the pairs of bridi-tails joined by multiple giheks can have its own set of tail-terms:

is equivalent in meaning to:

The literal English translation in Example 14.63 is almost unintelligible, but the Lojban is perfectly grammatical. mi fills the x1 place of all three selbri; lo rupnu is the x2 of dejni, whereas le cukta is a tail-term shared between dunda and lebna; la djan. is a tail-term shared by dejni and by dunda gi'abo lebna. In this case, greater clarity is probably achieved by moving la djan. to the beginning of the sentence, as in Example 14.53:

Finally, what about forethought logical connection of bridi-tails? There is no direct mechanism for the purpose. Instead, Lojban grammar allows a pair of forethought-connected sentences to function as a single bridi-tail, and of course the sentences need not have terms before their selbri. For example:

is equivalent in meaning to Example 14.50.

Of course, either of the connected sentences may contain giheks:

The entire gek-connected sentence pair may be negated as a whole by prefixing na:

Since a pair of sentences joined by geks is the equivalent of a bridi-tail, it may be followed by tail terms. The forethought equivalent of Example 14.54 is:

Here is a pair of gek-connected observatives, a forethought equivalent of Example 14.57:

Finally, here is an example of gek-connected sentences with both shared and unshared terms before their selbri:

So far we have seen sentences that differ in all components, and require bridi connection; sentences that differ in one sumti only, and permit sumti connection; and sentences that differ in the selbri and possibly one or more sumti, and permit bridi-tail connection. Termset logical connectives are employed for sentences that differ in more than one sumti but not in the selbri, such as:

The Lojban version of Example 14.71 requires two termsets joined by a logical connective. A “term” is either a sumti or a sumti preceded by a tense or modal tag such as pu or bai. Afterthought termsets are formed by linking terms together by inserting the cmavo ce'e (of selma'o CEhE) between each of them. Furthermore, the logical connective (which is a jek) must be prefixed by the cmavo pe'e (of selma'o PEhE). (We could refer to the combination of pe'e and a jek as a “pehejek”, I suppose.)

The literal translation uses “[plus]” to indicate the termset connective, and “[joint]” to indicate the position of the logical connective joint. As usual, there is an equivalent bridi-connection form:

which illustrates that the two bridi differ in the x2 and x3 places only.

What happens if the two joined sets of terms are of unequal length? Expanding to bridi connection will always make clear which term goes in which place of which bridi. It can happen that a sumti may fall in the x2 place of one bridi and the x3 place of another:

can be clearly understood by expansion to:

So le briju is your origin but my destination, and thus falls in the x2 and x3 places of klama simultaneously! This is legal because even though there is only one selbri, klama, there are two distinct bridi expressed here. In addition, mi in Example 14.74 is serving as a termset containing only one term. An analogous paradox applies to compound bridi with tail-terms and unequal numbers of sumti within the connected bridi-tails:

means that I go to the market from the office, and I walk to the office; le briju is the x3 place of klama and the x2 place of dzukla.

Forethought termsets also exist, and use nu'i of selma'o NUhI to signal the beginning and nu'u of selma'o NUhU (an elidable terminator) to signal the end. Nothing is inserted between the individual terms: they simply sit side-by-side. To make a logical connection in a forethought termset, use a gek, with the gek just after the nu'i, and an extra nu'u just before the gik:

Note that even though two termsets are being connected, only one nu'i is used.

The grammatical uses of termsets that do not contain logical connectives are explained in Section 9.8, Section 10.25, and Section 16.7.

As noted at the beginning of Section 14.9, there is no logical connective in Lojban that joins selbri and nothing but selbri. However, it is possible to have logical connectives within a selbri, forming a kind of tanru that involves a logical connection. Consider the simple tanru blanu zdani, blue house. Now anything that is a blue ball, in the most ordinary understanding of the phrase at least, is both blue and a ball. And indeed, instead of blanu bolci, Lojbanists can say blanu je bolci, using a jek connective within the tanru. (We saw jeks used in Section 14.11 also, but there they were always prefixed by pe'e; in this section they are used alone.) Here is a pair of examples:

But of course Example 14.78 and Example 14.79 are not necessarily equivalent in meaning! It is the most elementary point about Lojban tanru that Example 14.78 might just as well mean

and Example 14.79 certainly is not equivalent in meaning to Example 14.80.

A full explanation of logical connection within tanru belongs rather to a discussion of selbri structure than to logical connectives in general. Why? Because although Example 14.79 happens to mean the same as

and therefore as

the rule of expansion into separate bridi simply does not always work for tanru connection. Supposing Alice to be a person who lives in blue houses, then

would be true, because tanru grouping with a jek has higher precedence than unmarked tanru grouping, but:

is probably false, because the blueness is associated with the house, not with Alice, even leaving aside the question of what it means to say “Alice is a blue person”. (Perhaps she belongs to the Blue team, or is wearing blue clothes.) The semantic ambiguity of tanru make such logical manipulations impossible.

It suffices to note here, then, a few purely grammatical points about tanru logical connection. bo may be appended to jeks as to eks, with the same rules:

The components of tanru may be grouped with ke both before and after a logical connective:

where the first ke…ke'e pair may be omitted altogether by the rule of left-grouping, but is optionally permitted. In any case, the last instance of ke'e may be elided.

The syntax of jeks is:

parallel to eks and giheks.

Forethought tanru connection does not use geks, but uses guheks instead. Guheks have exactly the same form as geks:

Using guheks in tanru connection (rather than geks) resolves what would otherwise be an unacceptable ambiguity between bridi-tail and tanru connection:

Note that giks are used with guheks in exactly the same way they are used with geks. Like jeks, guheks bind more closely than unmarked tanru grouping does:

is the forethought version of Example 14.83.

A word of caution about the use of logically connected tanru within descriptions. English-based intuition can lead the speaker astray. In correctly reducing

to

there is a great temptation to reduce further to:

But Example 14.91 means that you see one thing which is both a man and a woman simultaneously! A nanmu je ninmu is a manwoman, a presumably non-existent creature who is both a nanmu and a ninmu.

So far we have addressed only sentences which are statements. Lojban, like all human languages, needs also to deal with sentences which are questions. There are many ways of asking questions in Lojban, but some of these (like questions about quantity, tense, and emotion) are discussed in other chapters.

The simplest kind of question is of the type “Is it true that ...” where some statement follows. This type is called a “truth question”, and can be represented in English by Example 14.92:

Note the two formulations. English truth questions can always be formed by prefixing “Is is true that” to the beginning of a statement; there is also usually a more idiomatic way involving putting the verb before its subject. “Is Fido a dog?” is the truth question corresponding to “Fido is a dog”. In Lojban, the equivalent mechanism is to prefix the cmavo xu (of selma'o UI) to the statement:

Example 14.92 and Example 14.93 are equivalent in meaning.

A truth question can be answered “yes” or “no”, depending on the truth or falsity, respectively, of the underlying statement. The standard way of saying “yes” in Lojban is go'i and of saying “no” is nago'i. (The reasons for this rule are explained in Section 7.6.) In answer to Example 14.93, the possible answers are:

and

Some English questions seemingly have the same form as the truth questions so far discussed. Consider

Superficially, Example 14.96 seems like a truth question with the underlying statement:

By translating Example 14.97 into Lojban and prefixing xu to signal a truth question, we get:

Given that Fido really is either a dog or a cat, the appropriate answer would be go'i; if Fido were a fish, the appropriate answer would be nago'i.

But that is not what an English-speaker who utters Example 14.96 is asking! The true significance of Example 14.96 is that the speaker desires to know the truth value of either of the two underlying bridi (it is presupposed that only one is true).

Lojban has an elegant mechanism for rendering this kind of question which is very unlike that used in English. Instead of asking about the truth value of the connected bridi, Lojban users ask about the truth function which connects them. This is done by using a special question cmavo: there is one of these for each of the logical connective selma'o, as shown by the following table:

(This list unfortunately departs from the pretty regularity of the other cmavo for logical connection. The two-syllable selma'o, GIhA and GUhA, make use of the cmavo ending in “-i” which is not used for a truth function, but gi and i were not available, and different cmavo had to be chosen. This table must simply be memorized, like most other non-connective cmavo assignments.)

One correct translation of Example 14.96 employs a question gihek:

Here are some plausible answers:

Example 14.103 is correct but uncooperative.

As usual, Lojban questions are answered by filling in the blank left by the question. Here the blank is a logical connective, and therefore it is grammatical in Lojban to utter a bare logical connective without anything for it to connect.

The answer gi'e, meaning that Alice is a dog and is a cat, is impossible in the real world, but for:

the answer e, meaning that I want both, is perfectly plausible, if not necessarily polite.

The forethought questions ge'i and gu'i are used like the others, but ambiguity forbids the use of isolated forethought connectives as answers – they sound like the start of forethought-connected bridi. So although Example 14.105 is the forethought version of Example 14.104:

the answer must be in afterthought form.

There are natural languages, notably Chinese, which employ the Lojbanic form of connective question. The Chinese sentence

means “Do you walk or run?”, and is exactly parallel to the Lojban:

However, Chinese does not use logical connectives in the reply to such a question, so the resemblance, though striking, is superficial.

Truth questions may be used in bridi connection. This form of sentence is perfectly legitimate, and can be interpreted by using the convention that a truth question is true if the answer is “yes” and false if the answer is no. Analogously, an imperative sentence (involving the special pro-sumti ko, which means “you” but marks the sentence as a command) is true if the command is obeyed, and false otherwise. A request of Abraham Lincoln's may be translated thus:

In logical terms, however, “but” is the same as “and”; the difference is that the sentence after a “but” is felt to be in tension or opposition to the sentence before it. Lojban represents this distinction by adding the discursive cmavo ku'i (of selma'o UI), which is explained in Section 13.12, to the logical .ije.)

Way back in Section 14.1, the point was made that not every use of English “and”, “if ... then”, and so on represents a Lojban logical connective. In particular, consider the “and” of:

Given the nature of pianos, this probably means that John carried one end and Alice the other. So it is not true that:

which would mean that each of them carried the piano by himself/herself. Lojban deals with this particular linguistic phenomenon as a “mass”. John and Alice are joined together into a mass, John-and-Alice, and it is this mass which carried the piano, not either of them separately. The cmavo joi (of selma'o JOI) is used to join two or more components into a mass:

Example 14.111 covers the case mentioned, where John and Alice divide the labor; it also could mean that John did all the hauling and Alice did the supervising. This possibility arises because the properties of a mass are the properties of its components, which can lead to apparent contradictions: if John is small and Alice is large, then John-and-Alice is both small and large. Masses are also discussed in Section 6.3.

Grammatically, joi can appear between two sumti (like an ek) or between two tanru components (like a jek). This flexibility must be paid for in the form of occasional terminators that cannot be elided:

The cmavo ku is the elidable terminator for le, which can almost always be elided, but not in this case. If the first ku were elided here, Lojban's parsing rules would see le nanmu joi and assume that another tanru component is to follow; since the second le cannot be part of a tanru, a parsing error results. No such problem can occur with logical connectives, because an ek signals a following sumti and a jek a following tanru component unambiguously.

Single or compound cmavo involving members of selma'o JOI are called joiks, by analogy with the names for logical connectives. It is not grammatical to use joiks to connect bridi-tails.

In tanru, joi has the connotation “mixed with”, as in the following example:

Here the ball is neither wholly blue nor wholly red, but partly blue and partly red. Its blue/redness is a mass property. (Just how blue something has to be to count as “wholly blue” is an unsettled question, though. A blanu zdani may be so even though not every part of it is blue.)

There are several other cmavo in selma'o JOI which can be used in the same grammatical constructions. Not all of them are well-defined as yet in all contexts. All have clear definitions as sumti connectives; those definitions are shown in the following table:

The cmavo se is grammatical before any JOI cmavo, but only useful with those that have inherent order. Here are some examples of joiks:

The x3 place of cuxna is a set from which the choice is being made. A set is an abstract object which is determined by specifying its members. Unlike those of a mass, the properties of a set are unrelated to its members' properties: the set of all rats is large (since many rats exist), but the rats themselves are small. This chapter does not attempt to explain set theory (the mathematical study of sets) in detail: explaining propositional logic is quite enough for one chapter!

In Example 14.114 we specify that set by listing the members with ce joining them.

The x2 place of liste is a sequence of the things which are mentioned in the list. (It is worth pointing out that lo liste means a physical object such as a grocery list: a purely abstract list is lo porsi, a sequence.) Here the three sumti connected by ce'o are in a definite order, not just lumped together in a set or a mass.

So joi, ce, and ce'o are parallel, in that the sumti connected are taken to be individuals, and the result is something else: a mass, a set, or a sequence respectively. The cmavo jo'u serves as a fourth element in this pattern: the sumti connected are individuals, and the result is still individuals – but inseparably so. The normal Lojban way of saying that James and George are brothers is:

possibly adding a discursive element meaning “and vice versa”. However, “James and George are brothers” cannot be correctly translated as:

since that expands to two bridi and means that James is a brother and so is George, but not necessarily of each other. If the e is changed to jo'u, however, the meaning of Example 14.116 is preserved:

The tanru remei bruna is not strictly necessary in this sentence, but is used to make clear that we are not saying that James and George are both brothers of some third person not specified. Alternatively, we could turn the tanru around: the x1 place of remei is a mass with two components, leading to:

where joi is used to create the necessary mass.

Likewise, fa'u can be used to put two individuals together where order matters. Typically, there will be another fa'u somewhere else in the same bridi:

Here the information carried by the English adverb “respectively”, namely that James loves Mary and George loves Martha, is divided between the two occurrences of fa'u. If both uses of fa'u were to be changed to e, we would get:

which can be transformed to four bridi:

which represents quite a different state of affairs from Example 14.120. The meaning of Example 14.120 can also be conveyed by a termset:

at the expense of re-ordering the list of names so as to make the pairs explicit. This option is not available when one of the lists is only described rather than enumerated:

which conveys that James loves one sister and George the other, though we are not able to tell which of the sisters is which.

The final three JOI cmavo, jo'e, ku'a, and pi'u, are probably only useful when talking explicitly about sets. They represent three standard set operators usually called “union”, “intersection”, and “cross product” (also known as “Cartesian product”). The union of two sets is a set containing all the members that are in either set; the intersection of two sets is a set containing all the members that are in both sets. The cross product of two sets is the set of all possible ordered pairs, where each ordered pair contains a single element from the first set followed by a single element from the second. This may seem very abstract; hopefully, the following examples will help:

There is a parallelism between logic and set theory that makes Example 14.125 and Example 14.126 equivalent respectively to:

and

The following example uses se remei, which is a set (not a mass) of two elements:

means that each of the pairs James/Mary, George/Mary, James/Martha, and George/Martha love each other. Therefore it is similar in meaning to Example 14.121; however, that example speaks only of the men loving the women, not vice versa.

Joiks may be combined with bo or with ke in the same way as eks and jeks; this allows grouping of non-logical connections between sumti and tanru units, in complete parallelism with logical connections:

asserts that there is a set of two items each of which is a mass.

Non-logical connection is permitted at the joint of a termset; this is useful for associating more than one sumti or tagged sumti with each side of the non-logical connection. The place structure of casnu is:

so the x1 place must be occupied by a mass (for reasons not explained here); however, different components of the mass may discuss in different languages. To associate each participant with his or her language, we can say:

Like all non-logical connectives, the usage shown in Example 14.131 cannot be mechanically converted into a non-logical connective placed at another location in the bridi. The forethought equivalent of Example 14.131 is:

Non-logical forethought termsets are also useful when the things to be non-logically connected are sumti preceded with tense or modal (BAI) tags:

Example 14.133 associates speaking in Lojban with John, and speaking under George's compulsion with Frank. We do not know what language Frank uses, or whether John speaks under anyone's compulsion.

Joiks may be prefixed with i to produce ijoiks, which serve to non-logically connect sentences. The ijoik .ice'o indicates that the event of the second bridi follows that of the first bridi in some way other than a time relationship (which is handled with a tense):

Example 14.134 represents a list of things to be done in priority order. The order is important, hence the need for a sequence connective, but does not necessarily represent a time order (the dog may end up getting walked first). Note the use of tu'e and tu'u as general brackets around the whole list. This is related to, but distinct from, their use in Section 14.8, because there is no logical connective between the introductory phrase mi ba gasnu la'edi'e and the rest. The brackets effectively show how large an utterance the word di'e, which means “the following utterance”, refers to.

Similarly, .ijoi is used to connect sentences that represent the components of a joint event such as a joint cause: the Lojban equivalent of “Fran hit her head and fell out of the boat, so that she drowned” would join the events “Fran hit her head” and “Fran fell out of the boat” with .ijoi.

The following nai, if present, does not negate either of the things to be connected, but instead specifies that some other connection (logical or non-logical) is applicable: it is a scalar negation:

The result of mi jo'u do would be two individuals, not a mass, therefore jo'u is not applicable; joi would be the correct connective.

There is no joik question cmavo as such; however, joiks and ijoiks may be uttered in isolation in response to a logical connective question, as in the following exchange:

Ugh. (Or in Lojban: .a'unaisairo'o.)

In addition to the non-logical connectives of selma'o JOI explained in Section 14.14 and Section 14.15, there are three other connectives which can appear in joiks: bi'i, bi'o, and mi'i, all of selma'o BIhI. The first two cmavo are used to specify intervals: abstract objects defined by two endpoints. The cmavo bi'i is correct if the endpoints are independent of order, whereas bi'o or sebi'o are used when order matters.

An example of bi'i in sumti connection:

In Example 14.138, it is all the same whether I am standing between Dresden and Frankfurt or between Frankfurt and Dresden, so bi'i is the appropriate interval connective. The sumti la drezdn. bi'i la frankfurt. falls into the x2 place of sanli, which is the surface I stand on; the interval specifies that surface by its limits. (Obviously, I am not standing on the whole of the interval; the x2 place of sanli specifies a surface which is typically larger in extent than just the size of the stander's feet.)

In Example 14.139, on the other hand, it is essential that la pacac. comes before la recac.; otherwise we have an 11-hour (or 23-hour) interval rather than a one-hour interval. In this use of an interval, the whole interval is probably intended, or at least most of it.

Example 14.139 is equivalent to:

English cannot readily express sebi'o, but its meaning can be understood by reversing the two sumti.

The third cmavo of selma'o BIhI, namely mi'i, expresses an interval seen from a different viewpoint: not a pair of endpoints, but a center point and a distance. For example:

Here we have an interval whose center is Washington and whose distance, or radius, is fifty miles.

In Example 14.138, is it possible that I am standing in Dresden (or Frankfurt) itself? Yes. The connectives of selma'o BIhI are ambiguous about whether the endpoints themselves are included in or excluded from the interval. Two auxiliary cmavo ga'o and ke'i (of cmavo GAhO) are used to indicate the status of the endpoints: ga'o means that the endpoint is included, ke'i that it is excluded:

As these examples should make clear, the GAhO cmavo that applies to a given endpoint is the one that stands physically adjacent to it: the left-hand endpoint is referred to by the first GAhO, and the right-hand endpoint by the second GAhO. It is ungrammatical to have just one GAhO.

(Etymologically, ga'o is derived from ganlo, which means “closed”, and ke'i from kalri, which means “open”. In mathematics, inclusive intervals are referred to as closed intervals, and exclusive intervals as open ones.)

BIhI joiks are grammatical anywhere that other joiks are, including in tanru connection and (as ijoiks) between sentences. No meanings have been found for these uses.

Negated intervals, marked with a -nai following the BIhI cmavo, indicate an interval that includes everything but what is between the endpoints (with respect to some understood scale):

The complete syntax of joiks is:

Notice that the colloquial English translations of bi'i and bi'o have forethought form: “between ... and” for bi'i, and “from ... to” for bi'o. In Lojban too, non-logical connectives can be expressed in forethought. Rather than using a separate selma'o, the forethought logical connectives are constructed from the afterthought ones by suffixing gi. Such a compound cmavo is not unnaturally called a “joigik”; the syntax of joigiks is any of:

Joigiks may be used to non-logically connect bridi, sumti, and bridi-tails; and also in termsets.

Example 14.111 in forethought becomes:

The first gi is part of the joigik; the second gi is the regular gik that separates the two things being connected in all forethought forms.

Example 14.143 can be expressed in forethought as:

In forethought, unfortunately, the GAhOs become physically separated from the endpoints, but the same rule applies: the first GAhO refers to the first endpoint.

Lojban has a separate grammar embedded within the main grammar for representing mathematical expressions (or mekso in Lojban) such as “2 + 2”. Mathematical expressions are explained fully in Chapter 18. The basic components of mekso are operands, like “2”, and operators, like “+”. Both of these may be either logically or non-logically connected.

Operands are connected in afterthought with eks and in forethought with geks, just like sumti. Operators, on the other hand, are connected in afterthought with jeks and in forethought with guheks, just like tanru components. (However, jeks and joiks with bo are not allowed for operators.) This parallelism is no accident.

In addition, eks with bo and with ke…ke'e are allowed for grouping logically connected operands, and ke…ke'e is allowed for grouping logically connected operators, although there is no analogue of tanru among the operators.

Only a few examples of each kind of mekso connection will be given. Despite the large number of rules required to support this feature, it is of relatively minor importance in either the mekso or the logical-connective scheme of things. These examples are drawn from Section 18.17, and contain many mekso features not explained in this chapter.

Example 14.149 exhibits afterthought logical connection between operands:

Example 14.150 is equivalent in meaning, but uses forethought connection:

Note that the mekso in Example 14.149 and Example 14.150 are being used as quantifiers. Lojban requires that any mekso other than a simple number be enclosed in vei and ve'o parentheses when used as a quantifier. The right parenthesis mark, ve'o, is an elidable terminator.

Simple examples of logical connection between operators are hard to come by. A contrived example is:

The forethought form of Example 14.151 is:

Non-logical connection with joiks or joigiks is also permitted between operands and between operators. One use for this construct is to connect operands with bi'i to create mathematical intervals:

You can also combine two operands with ce'o, the sequence connective of selma'o JOI, to make a compound subscript:

Note that the boi in Example 14.154 is not elidable, because the xi subscript needs something to attach to.
